Custom MMIC數字步進衰減器
發布時間：2021-01-18 16:59:27 瀏覽：1776
Custom MMIC提供多種多樣可變衰減器產品，具備高至50GHz的數字或模擬控制能力。Custom MMIC還有一系列以磁芯類型銷售的寬帶固定衰減器，其頻率可以達到50GHz。這類衰減器在絕緣子上應用領域硅(SOI)或PHEMT技術，在頻率領域、線性度、開關速率和魯棒性領域提供廣泛性的性能選擇。
主要特征
瞬態開關SOIDSA無超調
溫度補償，線性控制斜率SOIVCA
微波射頻PHEMT衰減器工作在50GHz
50ns快速開關衰減器
SOI：2ESD性能
典型應用領域
無線基礎設施
國防與航天
有線電視
微波射頻收音機
測試和測量
深圳市立維創展科技是Custom MMIC的經銷商，立維創展協助選取滿足需求的最合適的MMIC優化微波射頻射頻信號鏈。Custom MMIC是一個完整性的ISO認證和同類型絕佳MMICs經銷商。供應迅速增長的高性能射頻/微波射頻MMIC產品系列。
Part # | Frequency Min
MHz | Frequency Max
MHz | Insertion Loss
dB | Attenuation Range
dB | IP0.1dB
dBm | IIP3
dBm | Bits | Step Size
dB | Voltage
V | Package Type | Package
mm |
CMD279 | 2,000 | 30,000 | 3.5 | 15.5 | 27 | 42 | 5 | 0.5 | 5 | Die |
|
CMD279C3 | 2,000 | 18,000 | 3.5 | 15.5 | 27 | 42 | 5 | 0.5 | 5 | Ceramic QFN | 3.0 x 3.0 |
CMD280 | DC | 30,000 | 3 | 15.5 | 24 | 42 | 5 | 0.5 | -5 | Die |
|
CMD280C3 | DC | 18,000 | 3 | 15.5 | 24 | 42 | 5 | 0.5 | -5 | Ceramic QFN | 3.0 x 3.0 |
CMD281 | DC | 40,000 | 1.2 | 6 | 28 | 42 | 2 | 2 | -5 | Die |
|
CMD281C3 | DC | 22,000 | 1.5 | 6 | 28 | 42 | 2 | 2 | -5 | Ceramic QFN | 3.0 x 3.0 |
CMD282 | DC | 40,000 | 1.5 | 12 | 23 | 42 | 2 | 4 | -5 | Die |
|
CMD282C3 | DC | 22,000 | 1.9 | 12 | 23 | 42 | 2 | 4 | -5 | Ceramic QFN | 3.0 x 3.0 |
CMD324 | DC | 30,000 | 2.9 | 30 | 24 | 36 | 2 | 10 | -5 | Die |
|
CMD325 | DC | 30,000 | 4 | 31.5 | 26 | 40 | 6 | 0.5 | -5 | Die |
|
QPC3223 | 50 | 6,000 | 0.8 | 18 | 30 | > 55 | 2 | 6 | 3 to 5 | QFN | 3.0 x 3.0 |
QPC3614 | 5 | 1,500 | 1.2 | 31.5 | 30 | 65 | 6 | 0.5 | 5 | QFN | 4.2 x 4.2 |
QPC3624 | 47 | 2,000 | 1.3 | 31.5 | 30 | 60 | 6 | 0.5 | 5 | QFN | 4.0 x 4.0 x 0.85 |
QPC6614 | 5 | 6,000 | 1.4 | 31.5 | 30 | 55 | 6 | 0.5 | 5 | MCM, 24-Pin | 4.2 x 4.2 x 0.975 |
QPC6713 | 50 | 6,000 | 1.7 | 31.75 | 30 | 55 | 7 | 0.25 | 3 to 5 | QFN | 3.0 x 3.0 x 0.85 |
QPC6713Q | 50 | 6,000 | 1.7 @ 2000 MHz, 3.3 @ 5890 MHz | 31.75 | 30 | > 55 | 7 | 0.25 | 3 to 5 | QFN, 16 pad | 3.0 x 3.0 x 0.85 |
RFSA2534 | 50 | 4,000 | 1.3 | 15.5 | 30 | 52 | 5 | 0.5 | 2.7 to 5.5 | QFN, 24-pin | 4.2 x 4.2 x 0.95 |
RFSA3413 | 5 | 6,000 | 1.4 | 15 | 30 | 55 | 4 | 1 | 5 | QFN | 3.0 x 3.0 |
RFSA3513 | 5 | 6,000 | 1.4 | 31 | 30 | 55 | 5 | 1 | 5 | QFN | 3.0 x 3.0 |
RFSA3613 | 5 | 6,000 | 1.4 | 31.5 | 30 | 55 | 6 | 0.5 | 5 | QFN | 3.0 x 3.0 |
RFSA3713 | 5 | 6,000 | 1.4 | 31.75 | 30 | 55 | 7 | 0.25 | 5 | QFN | 3.0 x 3.0 |
RFSA3714 | 50 | 6,000 | 1.5 | 31.75 | 30 | 55 | 7 | 0.25 | 5 | QFN | 4.0 x 4.0 |
RFSA3715 | 5 | 4,000 | 1.5 | 31.75 | 30 | 50 | 7 | 0.25 | 5 | QFN | 5.0 x 5.0 |
TGL2223-SM | 1,000 | 31,000 | < 4.2 | 15.5 |
| > 32 | 5 | 0.5 | -3.3 to -5.0 | QFN | 3.0 x 3.0 x 1.45 |
TGL2226 | 100 | 15,000 | < 3.8 | 31.5 |
| > 31.5 | 6 | 0.5 | -3.0 to -5.0 | Die | 1.18 x 1.0 x 0.1 |
TGL2226-SM | 100 | 15,000 | < 4.0 | 31.5 |
| > 31.5 | 6 | 0.5 | -3.0 to -5.0 | SMT | 3.0 x 3.0 x 1.5 |
TQP4M9071 | 0 | 4,000 | 1.6 | 31.5 | 30 | 57 | 6 | 0.5 | 5 | QFN, 24-pin | 4.0 x 4.0 x 0.85 |
TQP4M9072 | 0 | 4,000 | 1.6 | 31.5 | 30 | 57 | 6 | 0.5 | 5 | QFN, 24-pin | 4.0 x 4.0 x 0.85 |
