ADI低噪聲運算放大器(≤ 10nV/√Hz)
發布時間：2021-10-08 16:44:37 瀏覽：6859
ADI低噪聲(≤10nV/√Hz)運算放大器產品系列包括許多具備行業內較低噪聲性能的放大器。這些高速、低失真（1nV或更?。┻\算放大器能夠在最嚴苛的情況下完成較高的信號保真度，讓系統開發工作人員能夠在具備更高源阻抗的應用中完成較低的系統總噪聲性能指標。ADI提供許多不同種類的這類放大器，它們具備寬電源電壓范圍和低功耗基本特性。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。
大部分產品，均提供現貨庫存供貨。
詳情了解ADI芯片請點擊：http://www.nfda.cn/brand/25.html
或聯系ADI的銷售工程師： 0755-83642657 QQ: 2295048674
產品型號 | # of Amps | GBP (typ) | Slew Rate (typ) | VNoise Density (typ) | 0.1 to 10 Hz VNoise (typ) | Current Noise Density (typ) | Iq/Amp (typ) | Vs span (min) | Vs span (max) |
|
| Hz | V/us | V/rtHz | V p-p | A/rtHz | A | V | V |
ADA4099-1 | 1 | 8M | 4 | 7n | 150n | 500f | 1.5m | 3.15 | 55 |
ADA4523-1 | 1 | 5M | 1.85 | 4.2n | 88n | 1p | 4.5m | 4.5 | 36 |
LTC6226 | 1 | 420M | 180 | 1n | 770n | 2.4p | 5.5m | 2.8 | 11.75 |
LTC6227 | 2 | 420M | 180 | 1n | 770n | 2.4p | 5.5m | 2.8 | 11.75 |
LTC6229 | 2 | 890M | 500 | 880p | 940n | 3p | 16m | 2.8 | 11.75 |
ADA4625-2 | 2 | 18M | 48 | 3.3n | 150n | 4.5f | 4m | 5 | 36 |
LTC6228 | 1 | 890M | 500 | 880p | 940n | 3p | 16m | 2.8 | 11.75 |
LTC2058 | 2 | 2.5M | 1.6 | 9n | 200n | 500f | 950μ | 4.75 | 36 |
ADA4084-4S | 4 |
|
|
|
|
|
| 3 | 30 |
ADA4625-1 | 1 | 18M | 48 | 3.3n | 150n | 4.5f | 4m | 5 | 36 |
LT6275 | 2 | 40M | 2.2k | 10n | 1μ | 500f | 1.6m | 9 | 32 |
LT1210X | 1 |
| 900 | 3n |
| 2p | 35m | 10 | 30 |
LT6203X | 2 | 83M | 24 | 2n | 800n | 750f | 3.3m | 2.5 | 12.6 |
LT6274 | 1 | 40M | 2.2k | 10n | 1μ | 500f | 1.6m | 9 | 32 |
LT6018 | 1 | 15M | 30 | 1.2n | 30n | 3p | 7.2m | 8 | 33 |
ADA4522-1 | 1 | 2.7M | 1.7 | 5.8n | 117n | 800f | 840μ | 4.5 | 55 |
LTC6253-7 | 2 | 2G | 500 | 2.75n | 2μ | 4p | 3.3m | 2.5 | 5.25 |
ADA4522-4 | 4 | 2.7M | 1.7 | 5.8n | 117n | 800f | 830μ | 4.5 | 55 |
ADA4806-1 | 1 | 30M | 160 | 5.2n |
| 700f | 570μ | 3 | 10 |
ADA4807-4 | 4 | 200M | 225 | 3.3n | 160n | 700f | 1m | 2.7 | 11 |
ADA4522-2 | 2 | 2.7M | 1.7 | 5.8n | 117n | 800f | 830μ | 4.5 | 55 |
ADA4084-2S | 2 |
|
|
|
|
|
| 3 | 30 |
ADA4177-1 | 1 | 3.5M | 1.5 | 8n | 175n | 200f | 500μ | 10 | 30 |
ADA4350 | 1 | 175M | 100 | 5n |
| 1.1p | 8.5m | 3.3 | 12 |
ADA4610-1 | 1 | 16.3M | 25 | 7.3n | 450n | 1f | 1.6m | 10 | 36 |
ADA4807-2 | 2 | 200M | 225 | 3.3n | 160n | 700f | 1m | 2.7 | 11 |
LTC6268-10 | 1 | 4G | 1.5k | 4n | 12.6μ | 7f | 16.5m | 3.1 | 5.25 |
LTC6269-10 | 2 | 4G | 1.5k | 4n | 12.6μ | 7f | 16.5m | 3.1 | 5.25 |
ADA4177-4 | 4 | 3.5M | 1.5 | 8n | 175n | 200f | 500μ | 10 | 30 |
ADA4807-1 | 1 | 200M | 225 | 3.3n | 160n | 700f | 1m | 2.7 | 11 |
ADA4177-2 | 2 | 3.5M | 1.5 | 8n | 175n | 200f | 500μ | 10 | 30 |
ADA4805-2 | 2 | 30M | 190 | 5.2n | 300n | 700f | 570μ | 2.7 | 10 |
LTC6268 | 1 | 500M | 400 | 4.3n | 13μ | 5.5f | 16.5m | 3.1 | 5.25 |
LTC6269 | 2 | 500M | 400 | 4.3n | 13μ | 5.5f | 16.5m | 3.1 | 5.25 |
ADA4084-1 | 1 | 15.9M | 4.6 | 3.9n | 100n | 550f | 565μ | 3 | 30 |
ADA4610-4 | 4 | 16.3M | 25 | 7.3n | 450n | 1f | 1.6m | 10 | 36 |
ADA4805-1 | 1 | 30M | 190 | 5.2n | 300n | 700f | 570μ | 2.7 | 10 |
ADA4870 | 1 |
| 2.5k | 2.1n |
| 4.2p | 32.5m | 10 | 40 |
ADA4077-1 | 1 | 3.9M | 1 | 7n | 250n | 200f | 400μ | 5 | 30 |
ADA4084-4 | 4 | 15.9M | 4.6 | 3.9n | 100n | 550f | 565μ | 3 | 30 |
ADA4077-4 | 4 | 3.9M | 1 | 7n | 250n | 200f | 400μ | 5 | 30 |
LT6238 | 4 | 215M | 60 | 1.1n | 180n | 1p | 3.15m | 3 | 12.6 |
AD8634 | 2 | 9.7M | 5 | 4.2n | 130n | 600f | 1.1m | 3 | 30 |
LT6236 | 1 | 215M | 60 | 1.1n | 180n | 1p | 3.15m | 3 | 12.6 |
LT6237 | 2 | 215M | 60 | 1.1n | 180n | 1p | 3.15m | 3 | 12.6 |
ADA4895-1 | 1 | 1.5G | 943 | 1n | 99n | 1.6p | 3m | 3 | 10 |
ADA4077-2 | 2 | 3.9M | 1 | 7n | 250n | 200f | 400μ | 5 | 30 |
