ADI差動放大器
發布時間：2022-01-11 17:05:46 瀏覽：1091
差動放大器是一款特殊領域放大器，設計適用于檢測差分信號，也稱為減法器。ADI差動放大器能夠清除影響共模信號，選用的方法稱為共模抑制(CMR)，這是它的一項主要領域。與大多數類型的放大器不同，ADI差動放大器通常能夠檢測超過供電軌的電壓，適用于具有較大直流電或交流共模電壓的應用領域。ADI差動放大器為實現低失真、低功耗或高電壓性能實現了優化。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。
大部分產品，均提供現貨庫存供貨。
產品型號 | # of Amps | Common Mode In (min) | Common Mode In (max) | Gain (min) | Gain (max) | BW - low gain (typ) | Slew Rate (typ) | Iq/Amp (max) | Vs span (min) | Vs span (max) |
|
| V | V | V/V | V/V | Hz | V/us | A | V | V |
LT1997-1 | 1 | -300m | 80 | 0.141 | 80 | 650k | 4 | 400μ | 3.3 | 50 |
LT1997-2 | 1 | -255 | 255 | 0.0455 | 0.55 | 1M | 750m | 400μ | 3.3 | 50 |
LT1997-3 | 1 | -160 | 160 | 0.077 | 13 | 1.1M | 750m | 400μ | 3.3 | 50 |
LT6376 | 1 | -230 | 230 | 10 | 10 | 160k | 4.1 | 400μ | 3.3 | 50 |
LT6375 | 1 | -270 | 270 | 1 | 1 | 375k | 2.4 | 400μ | 3.3 | 50 |
AD8479 | 1 | -600 | 600 | 1 | 1 | 310k | 8.8 | 650μ | 5 | 36 |
ADA4830-2 | 2 | -10 | 9.5 | 0.5 | 0.5 | 84M | 300 | 10m | 2.9 | 5.5 |
ADA4830-1 | 1 | -10 | 9.5 | 0.5 | 0.5 | 84M | 300 | 10m | 2.9 | 5.5 |
AD8208 | 1 | -2 | 45 | 20 | 20 | 70k | 1 | 3m | 4.5 | 5.5 |
AD8209 | 1 | -2 | 45 | 14 | 14 | 80k | 1 | 3m | 4.5 | 5.5 |
AD8279 | 2 | -45.3 | 40.5 | 0.5 | 2 | 1M | 1.3 | 350μ | 2 | 36 |
AD8277 | 2 | -30.2 | 27 | 1 | 1 | 550k | 1.1 | 200μ | 2 | 36 |
AD8278 | 1 | -45.3 | 40.5 | 0.5 | 2 | 1M | 1.4 | 200μ | 2 | 36 |
AD8276 | 1 | -30.2 | 27 | 1 | 1 | 550k | 1.1 | 200μ | 2 | 36 |
AD8271 | 1 | -15.4 | 15.4 | 0.5 | 2 | 20M | 30 | 2.6m | 5 | 36 |
AD8274 | 1 | -40.5 | 40.5 | 0.5 | 2 | 20M |
| 2.6m | 5 | 36 |
AD8275 | 1 | -12.3 | 12 | 0.2 | 0.2 | 15M | 25 | 2.3m | 3.3 | 15 |
AD8270 | 2 | -15.4 | 15.4 | 0.5 | 2 | 20M | 30 | 2.5m | 5 | 36 |
AD8273 | 2 | -40.5 | 40.5 | 0.5 | 3 | 20M | 20 | 2.5m | 5 | 36 |
LT1996 | 1 | -60 | 60 | 9 | 117 | 560k | 120m | 110μ | 2.7 | 36 |
LT1990 | 1 | -250 | 250 | 1 | 10 | 100k | 550m | 180μ | 2.4 | 36 |
LT1990-10 | 1 | -250 | 250 | 10 | 10 | 100k | 400m | 180μ | 2.4 | 36 |
LT1991 | 1 | -18 | 18 | 1 | 13 | 560k | 120m | 110μ | 2.4 | 40 |
LT1995 | 1 | -15 | 15 | 1 | 7 | 32M | 1k | 8.5m | 5 | 30 |
AD628 | 1 | -120 | 120 | 0.1 | 100 | 600k | 300m | 1.6m | 4.5 | 36 |
AD629 | 1 | -270 | 270 | 1 | 1 | 500k | 2.1 | 1m | 5 | 36 |
AD626 | 1 | -24 | 24 | 10 | 100 | 100k | 220m | 2m | 2.4 | 10 |
AMP03 | 1 | -20 | 20 | 1 | 1 | 3M | 9.5 | 3.5m | 10 | 36 |
