Custom MMIC有線電視 (CATV) 放大器
發布時間：2022-01-26 13:48:46 瀏覽：1229
2020年2月，射頻微波解決方案的領先供應商Qorvo宣布已經完成Custom MMIC的收購。Custom MMIC主要用于國防科技、航空航天和商業服務應用領域GaAs和GaN單芯片微波集成電路(MMIC)領先供應商。Qorvo基礎設施與國防科技產品(IDP)機構的組成部分，Custom MMIC團隊將繼續用在國防科技陣列和AESA產品拓展毫米波功能模塊雷達、電子戰、衛星通訊、無線回程和微波測試設備。
Qorvo有線電視(CATV)放大器包含單端、雙路和差分放大器，主要用于各種各樣75歐姆應用領域。這些機器設備提供多功能性和經濟性，支持三重播放要求、系統升級和新部署。
主要特點
單端和差分配置
一流的高線性度
低功耗
3V 至 12V
典型應用
有線電視
光纖到戶 (FTTH)
衛星電視 (SATV)
深圳市立維創展科技是CUSTOM MMIC/Qorvo 的經銷商，立維創展協助選取滿足需求的最合適的MMIC優化微波射頻射頻信號鏈。擁有穩定的供貨渠道，優勢提供Qorvo 陶瓷封裝IC和裸芯片產品，并大量備有現貨庫存，歡迎咨詢。
詳情了解Custom MMIC請點擊：http://www.nfda.cn/brand/2.html
Part # | Frequency Min
MHz | Frequency Max
MHz | Gain
dB | Pout
dBmV | CSO
dBc | CTB
dBc | XMOD
dBc | NF
dB | Voltage
V | Current
mA |
AG606-G | DC | 1,000 | 13.5 |
|
|
|
| 4.5 | > 7 | 165 |
CXE-2022Z | 45 | 1,003 | 17.5 |
| -65 | -75 | -80 | 1.2 | 3.3 | 20 |
QPA3359 | 45 | 1,218 | 28 | 44 | -75 | -72 | -66 | 4.5 | 24 | 260 |
QPA4425 | 45 | 1,218 | 25 | > 47 | -70 | -75 |
| 4.5 | 24 | 290 |
QPA4428 | 45 | 1,218 | 28 | > 47 | -70 | -75 |
| 4.5 | 24 | 290 |
QPA5368 | 5 | 300 | 35.6 | 44 | -62 | -59 | -59 | 4.1 | 12 | 195 |
QPA8801 | 45 | 1,218 | 11 | 49 | -70 | -78 |
| 5.5 | 12 | 380 |
QPA8840 | 50 | 1,800 | 22 | 69 |
|
|
| 4.2 | 12 | 425 |
QPB0066 | 5 | 500 | 44 |
|
|
|
| 4.3 | 5 | 500 |
QPB2318 | 5 | 210 | 15.5 |
|
|
|
| 3.8 | 8 | 235 |
QPB2328 | 5 | 210 | 17.8 |
|
|
|
| 3.5 | 8 | 235 |
QPB3311 | 5 | 210 | 15.2 |
|
|
|
| 3.8 | 8 | 172 |
QPB3321 | 5 | 210 | 17.5 |
|
|
|
| 3.4 | 8 | 170 |
QPB7400 | 45 | 1,218 | 10.5 |
|
|
|
| 3.5 | 5 | 110 |
QPB7420 | 47 | 1,218 | 20.4 |
| 60 | 77 |
| 1.1 | 5 | 55 |
QPB7425 | 47 | 1,218 | 25 |
| 57 | 69 |
| 1.1 | 8 | 100 |
QPB8808 | 50 | 1,218 | 20.6 |
|
|
|
|
| 12 | 525 |
QPB8857 | 47 | 1,218 | 28 | 57 | -68 | -75 |
| 4.5 | 24 | 440 |
QPB8858 | 47 | 1,218 | 34 | 47 | -70 | -75 |
| 4 | 24 | 290 |
QPB8896 | 5 | 700 | 25 |
|
|
|
| 1.8 | 5 | 275 |
QPB8957 | 47 | 1,000 | 28 | 56 | -70 | -75 |
| 4.5 | 24 | 350 |
QPB8958 | 47 | 1,000 | 34 | 46 | -70 | -75 |
| 4 | 24 | 240 |
QPL1810 | 50 | 1,800 | 20 | 20 |
|
|
| 1.2 | 5 | 100 |
QPL1811 | 50 | 1,800 | 16 | 24 |
|
|
| 3.5 | 7 | 290 |
QPL1812 | 50 | 1,800 | 19 | 21 |
|
|
| 3.5 | 8 | 180 |
QPL1816 | 50 | 1,800 | 10 | 55 |
|
|
| 2.5 | 6 | 120 |
QPL1818 | 50 | 1,800 | 15 | 56 |
|
|
| 2 | 5 | 100 |
QPL7433 | 50 | 3,300 | 17.5 |
|
|
|
| 1.5 | 5 | 90 |
QPL8830 | 5 | 1,218 | 21 | 34 | -85 | -77 |
| 3.2 | 5 | 280 |
QPL8831 | 5 | 1,218 | 17 | 34 | -85 | -77 |
| 3.2 | 5 | 280 |
QPL8832 | 5 | 1,218 | 19 | 34 | -85 | -77 |
| 3.2 | 5 | 280 |
QPL8833 | 5 | 1,218 | 15 | 34 | -85 | -77 |
| 3.2 | 5 | 280 |
QPL8834 | 5 | 1,218 | 12 | 34 | -85 | -77 |
| 3.2 | 5 | 280 |
RF2312 | 5 | 725 | 15.5 typical | 20 dbm | -76 | -86 |
|
| 5 | 100 |
RF2317 | 5 | 3,000 | 14.6 up, 15 down | 49.5 up, 25 down | -61 up, -65 down | -84 up, -85 down | < -70 down | 3.7 up, 4.8 down | 9 | 180 |
RFAM3620 | 45 | 1,218 | 36 | 48 | -75 | -73 | -70 | 5 | 12 | 510 |
RFAM3790 | 45 | 1,218 | 28.5 | 45 | -70 | -67 | -61 | 4 | 12 | 410 |
RFCA1008 | 5 | 1,003 | 17.4 | 50 up, 34 down | -80 up, -80 down | -67 up, -76 down |
| 4 | 5 | 217 |
RFCA3828 | 45 | 1,218 | 22 | 30 | -68 | -82 | -77 | 1.5 | 6 | 169 |
RFCA8828 | 45 | 1,218 | 16.4 | 34 | -93 | -85 | -76 | 2.8 | 6 | 360 |
RFCA8830 | 45 | 1,218 | 19.2 | 34 | -85 | -77 | -63 | 2.5 | 5 | 277 |
RFCM3328 | 45 | 1,218 | 25 |
|
|
|
|
|
| 480 |
RFCM4363 | 45 | 1,218 | 28 | 45 | -76 | -72 | -65 | 4.6 | 24 | 250 |
RFCM5304 | 5 | 220 | 39.2 | 50 | -70 | -70 |
| 2.9 | 12 | 205 |
TAT7427B | 45 | 1,003 | 18.5 | 28.5 | -70 | -88 |
| 2.5 | 6 | 145 |
TAT7430B | 45 | 1,003 | 22 | 32 | -61 | -81 |
| 2 | 8 | 190 |
TAT7457 | 5 | 1,218 | 19 | 50 up, 29 down | -58 up, -66 down | -67 up, -78 down |
| 2 | 5 | 120 |
TAT7460 | 50 | 2,600 | 16.5 |
|
|
|
| 2.5 | 5 | 100 |
TAT7461 | 45 | 1,003 | 16.1 | 26 | -72 | -88 |
| 2.3 | 6 | 130 |
TAT7467E1F | 45 | 1,218 | 18 | 40 | -75 | -70 | -82 | 4.7 | 5 | 380 |
TAT7472A1F | 45 | 1,218 | 15.4 | 41 | -82 | -76 |
| 2.4 | 5 | 320 |
TAT8804D1H | 50 | 1,200 | 21 |
|
|
|
| 4.5 | 12 | 650 |
TGA2803-SM | 45 | 1,218 | 20 | 39 | -76 | -78 |
| 1.5 | 8 | 360 |
