ADI單電源電壓輸出DAC
發布時間：2022-05-17 17:04:57 瀏覽：1678
ADI在行業內提供全套低壓單電源數模轉換器，包含許多在性能和封裝規格尺寸方面具備頂尖優勢的器件。許多應用需要選用ADI單電源電壓輸出DAC，因為它們具備非常小的總體規格尺寸和一系列穩定特性，包含8-16位分辨率、低功耗、迅速的50MHz SPI或3.4MHz I2C端口，并且選用中小型封裝。ADI單電源電壓輸出DAC提供了各種各樣增強性能，例如更高的精度、改善的直流性能、增強的穩定性、更低的毛刺能量和許多其他優勢。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。大部分產品，均提供現貨庫存供貨。
詳情了解ADI芯片請點擊：http://www.nfda.cn/brand/25.html
產品型號 | Channels | Resolution | DAC INL (max) | Output Range | Settling Time (typ) |
|
| bits | LSBs |
| s p-p |
AD5673R-1 | 16 | 12 | 1 | 0V to 2.5V, 0V to 5V | 6μ |
AD5673R-2 | 16 | 12 | 1 | 0V to 2.5V, 0V to 5V | 6μ |
AD5677R-1 | 16 | 16 | 4 | 0V to 2.5V, 0V to 5V | 6μ |
AD5677R-2 | 16 | 16 | 4 | 0V to 2.5V, 0V to 5V | 6μ |
AD5600 | 1 | 16 | 17 | 0V to 5.5V | 30μ |
AD5674 | 16 | 12 | 1 | 0 to 5V, 0V to 2.5V | 6μ |
AD5674R-1 | 16 | 12 | 1 | 0 to 5V, 0V to 2.5V | 6μ |
AD5679-1 | 16 | 16 | 4 | 0V to 2.5V, 0V to 5V | 6μ |
AD5679R-1 | 16 | 16 | 4 | 0V to 2.5V, 0V to 5V | 6μ |
AD5753 | 1 | 16 | 4 | ±10V, ±12V, ±20mA, ±24mA, ±5V, 0mA to 20mA, 0mA to 24mA, 0V to 10V, 0V to 5V, 0V to 6V, -1mA to 22mA, 4mA to 20mA | 15μ |
LTC2664-12 | 4 | 12 | 1 | ±10V, ±2.5V, ±5V, 0V to 10V, 0V to 5V | 4.5μ |
LTC2664-16 | 4 | 16 | 4 | ±10V, ±2.5V, ±5V, 0V to 10V, 0V to 5V | 9μ |
LTC2666-12 | 8 | 12 | 1 | ±10V, ±2.5V, ±5V, 0V to 10V, 0V to 5V | 4.5μ |
LTC2666-16 | 8 | 16 | 4 | ±10V, ±2.5V, ±5V, 0V to 10V, 0V to 5V | 4.5μ |
AD5761 | 1 | 16 | 2 | ±10V, ±3V, ±5V, 0V to 10V, 0V to 16V, 0V to 20V, 0V to 5V, -2.5V to 7.5V | 9μ |
AD5675 | 8 | 16 | 3 | 0V to 2.5V, 0V to 5.5V | 5μ |
AD5721 | 1 | 12 | 0.5 | ±10V, ±3V, ±5V, 0V to 10V, 0V to 16V, 0V to 20V, 0V to 5V, -2.5V to 7.5V | 9μ |
AD5761R | 1 | 16 | 2 | ±10V, ±3V, ±5V, 0V to 10V, 0V to 16V, 0V to 20V, 0V to 5V, -2.5V to 7.5V | 9μ |
AD5592R | 8 | 12 | 1 | 0 to 5V |
|
AD5593R | 8 | 12 | 1 | 0 to 5V |
|
AD5671R | 8 | 12 | 1 | 0V to 2.5V, 0V to 5V | 5μ |
AD5672R | 8 | 12 | 1 | 0V to 2.5V, 0V to 5V | 5μ |
AD5675R | 8 | 12 | 3 | 0V to 2.5V, 0V to 5V | 5μ |
AD5676 | 8 | 16 | 3 | 0V to 2.5V, 0V to 5V | 5μ |
