Model | Band | Frequency (GHz) | Insertion Loss (dB) | Return Loss (dB) | Power Handling (W) | Waveguide Port | Coaxial Port |
411(34)/595/KF | WR-34 | 22-33 | 0.4 | 17 | 20 | WR-34 Waveguide, UG-595/U-M Flange | K-Female (2.92) connector |
411(34)/595/KM | WR-34 | 22-33 | 0.4 | 20 | 20 | WR-34 Waveguide, UG-595/U-M Flange | K-Male (2.92) connector |
411K/595/2.4mmF | K-Band | 18.5-26.5 | 0.3 | 16 | 20 | WR-42 Waveguide, UG-595/U Flange | K (2.92 mm) Female connector |
411K/595/KM | K-Band | 18.5-26.5 | 0.3 | 20 | 20 | WR-42 Waveguide, UG-595/U Flange | K-Male connector |
411K/595/2.4mmF | K-Band | 18.5-26.5 | 0.3 | 17 | 20 | WR-42 Waveguide, UG-595/U Flange | K (2.92 mm) Female connector |
411K/595/SMAM | K-Band | 18.5-26.5 | 0.4 | 20 | 20 | WR-42 Waveguide, UG-595/U Flange | SMA-Male |
411A/599/KM | Ka-Band | 26.5-40 | 0.4 | 20 | 20 | WR-28 Waveguide, UG-599/U Flange | K-Male (2.92) connector |
411A/599/KF | Ka-Band | 26.5-40 | 0.4 | 17 | 20 | WR-28 Waveguide, UG-599/U Flange | K-Female (2.92) connector |
411B/383/2.4mmM | Q-Band | 33-50 | 0.7 | 17 | 15 | WR-22 Waveguide, UG-383/U Flange | 2.4mm Male connector |
411B/383/2.4mmF | Q-Band | 33-50 | 0.7 | 17 | 15 | WR-22 Waveguide, UG-383/U Flange | 2.4mm Female connector |
411B/383/1.85mmF | Q-Band | 33-50 | 0.7 | 20 | 15 | WR-22 Waveguide, UG-383/U Flange | 1.85mm Female connector |
411B/383/1.85mmF | Q-Band | 33-50 | 0.7 | 20 | 15 | WR-22 Waveguide, UG-383/U Flange | 1.85mm Female connector |
411B/383/2.4mmM | Q-Band | 33-40 | 0.7 | 17 | 15 | WR-22 Waveguide, UG-383/U Flange | 2.4mm Male connector |
411B/719/2.4mmF | Q-Band | 33-50 | 0.7 | 20 | 15 | WR-22 Waveguide, UG-719/U Square Flange | 2.4mm Female connector |
411U/383/1.85mmF | U-Band | 40-60 | 0.7 | 20 | 10 | WR-19 Waveguide, UG-383/U-M Flange | 1.85mm Female connector |
411U/383/1.85mmM | U-Band | 40-60 | 0.7 | 20 | 10 | WR-19 Waveguide, UG-383/U-M Flange | 1.85mm Male connector |
411V/385/1.85mmF | V-Band | 50-75 | 0.7 | 20 | 10 | WR-15 Waveguide, UG-385/U Flange | 1.85mm Female connector |
411V/385/1.85mmM | V-Band | 50-75 | 0.7 | 20 | 10 | WR-15 Waveguide, UG-385/U Flange | 1.85mm Male connector |
411V/385/1.85mmF | V-Band | 50-75 | 0.7 | 20 | 10 | WR-15 Waveguide, UG-385/U Flange | 1.85 mm Female connector |
411V/385/1.00mmF | V-Band | 50-75 | 1 | 15 | 5 | WR-15 Waveguide, UG-385/U Flange | 1.00 mm Female connector |
411E/387/1.00mmF | E-Band | 60-90 | 1 | 14 | 5 | WR-12 Waveguide, UG-387/U Flange | 1.00 mm Female connector |
411E/387/1.00mmM | E-Band | 60-90 | 1 | 14 | 5 | WR-12 Waveguide, UG-387/U Flange | 1.00 mm Male connector |
411W/387/1.00mmF | W-Band | 75-110 | 1 | 14 | 5 | WR-10 Waveguide, UG-387/U-M Flange | 1.00 mm Female connector |
411W/387/1.00mmM | W-Band | 75-110 | 1 | 14 | 5 | WR-10 Waveguide, UG-387/U-M Flange | 1.00 mm Male connector |
