?ADI高速運算放大器（帶寬 ≥ 50MHz）
發布時間：2023-01-09 16:49:52 瀏覽：6434
ADI高速運算放大器適用于儀器儀表、電信網絡、實驗室和醫療系統等高性能數據采集系統。ADI高速運算放大器產品范圍從50MHz到GHz，可大幅度降低功能損耗，是全球最暢銷的調節功放品牌。憑借廣泛的領先產品，從寬帶寬到高電壓擺幅率到低失真，ADI為下一代設計設定了與眾不同的性能標準。ADI是高速運算放大器的最終來源，當設計人員需要可靠的器件來實現其設計中的高性能時。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。大部分產品，均提供現貨庫存供貨。
詳情了解ADI芯片請點擊：http://www.nfda.cn/brand/25.html
產品型號 | # of Amps | GBP (typ) | BW -3 dB (typ) | Slew Rate (typ) | VNoise Density (typ) | Iq/Amp (typ) | Vs span (min) | Vs span (max) |
|
| Hz | Hz | V/us | V/rtHz | A | V | V |
LTC6226 | 1 | 420M | 330M | 180 | 1n | 5.5m | 2.8 | 11.75 |
LTC6227 | 2 | 420M | 330M | 180 | 1n | 5.5m | 2.8 | 11.75 |
LTC6229 | 2 | 890M | 730M | 500 | 880p | 16m | 2.8 | 11.75 |
LTC6228 | 1 | 890M | 730M | 500 | 880p | 16m | 2.8 | 11.75 |
LT1210X | 1 |
| 55M | 900 | 3n | 35m | 10 | 30 |
LT6203X | 2 | 83M |
| 24 | 2n | 3.3m | 2.5 | 12.6 |
LT6274 | 1 | 40M | 90M | 2.2k | 10n | 1.6m | 9 | 32 |
LTC6253-7 | 2 | 2G |
| 500 | 2.75n | 3.3m | 2.5 | 5.25 |
ADA4806-1 | 1 | 30M | 105M | 160 | 5.2n | 570μ | 3 | 10 |
ADA4807-4 | 4 | 200M | 180M | 225 | 3.3n | 1m | 2.7 | 11 |
ADA4350 | 1 | 175M | 55M | 100 | 5n | 8.5m | 3.3 | 12 |
ADA4807-2 | 2 | 200M | 180M | 225 | 3.3n | 1m | 2.7 | 11 |
LTC6268-10 | 1 | 4G |
| 1.5k | 4n | 16.5m | 3.1 | 5.25 |
LTC6269-10 | 2 | 4G |
| 1.5k | 4n | 16.5m | 3.1 | 5.25 |
ADA4807-1 | 1 | 200M | 180M | 225 | 3.3n | 1m | 2.7 | 11 |
ADA4805-2 | 2 | 30M | 105M | 190 | 5.2n | 570μ | 2.7 | 10 |
LTC6268 | 1 | 500M |
| 400 | 4.3n | 16.5m | 3.1 | 5.25 |
LTC6269 | 2 | 500M |
| 400 | 4.3n | 16.5m | 3.1 | 5.25 |
ADA4805-1 | 1 | 30M | 105M | 190 | 5.2n | 570μ | 2.7 | 10 |
ADA4870 | 1 |
| 52M | 2.5k | 2.1n | 32.5m | 10 | 40 |
LT6238 | 4 | 215M |
| 60 | 1.1n | 3.15m | 3 | 12.6 |
LT6236 | 1 | 215M |
| 60 | 1.1n | 3.15m | 3 | 12.6 |
LT6237 | 2 | 215M |
| 60 | 1.1n | 3.15m | 3 | 12.6 |
ADA4895-1 | 1 | 1.5G | 236M | 943 | 1n | 3m | 3 | 10 |
ADA4312-1 | 2 |
| 195M | 2.1k | 57n | 46m | 12 | 12 |
ADA4895-2 | 2 | 1.5G | 236M | 943 | 1n | 3m | 3 | 10 |
MAX44280 | 1 | 50M | 50M | 30 | 12.7n | 750μ | 1.7 | 5.5 |
ADA4897-2 | 2 | 90M | 230M | 120 | 1n | 3m | 3 | 10 |
LTC6360 | 1 | 1G | 250M | 135 | 2.3n | 13.6m | 4.75 | 5.25 |
ADA4896-2 | 2 | 90M | 230M | 120 | 1n | 3m | 3 | 10 |
ADA4897-1 | 1 | 90M | 230M | 120 | 1n | 3m | 3 | 10 |
RH6200M | 1 | 165M |
| 44 | 1.1n | 16.5m | 4.5 | 12.6 |
ADA4637-1 | 1 | 79.9M |
| 170 | 4.8n | 7m | 9 | 30 |
ADA4800 | 1 |
| 400M | 415 | 1.5n | 1.4m | 4 | 17 |
ADA4891-3 | 3 | 105M | 220M | 170 | 9n | 4.4m | 2.7 | 5.5 |
ADA4891-4 | 4 | 105M | 220M | 170 | 9n | 4.4m | 2.7 | 5.5 |
ADA4891-1 | 1 | 105M | 240M | 170 | 9n | 4.4m | 2.7 | 5.5 |
