ADI基带差分低通滤波器
发布时间：2024-01-18 16:52:20 浏览：674
低通滤波器能够通过清除高频信号的形式来过滤模拟输入中的高频噪音或电磁干扰，从而使输出信号更平稳、效率更高。
ADI固定和可调谐宽带全差分低通滤波器产品系列兼容诸多的通信网络、脉冲调制和RFID技术应用，工作带宽高至25MHz。ADI基带差分低通滤波器能提供单通道和双通道电子器件选择。
产品型号 | Filter Order | Filters Per Package (typ) | Preconfigured | Realization | Fo Max (typ) | Gain Range | Filter |
| order |
|
|
| Hz |
|
|
LTC6601-2 | 2 | 1 | Differential, Lowpass | Pin Configurable | 25M | 1 | 5MHz - 27MHz Low Pass |
LTC6601-1 | 2 | 1 | Differential, Lowpass | Pin Configurable | 25M | 1 | 5MHz - 28MHz Lowpass |
LTC6602 | 9 | 2 | Bandpass, Differential | Elliptic | 900k | 1, 16, 32V/V, 4, 8 | 150kHz - 900kHz Low Pass / Band Pass |
LTC6603 | 9 | 2 | Differential, Lowpass | Elliptic | 2.5M | 0dB, 12dB, 24dB, 6dB | 156kHz - 2.5MHz Low Pass |
LTC6605-10 | 2 | 2 | Differential, Lowpass | Pin Configurable | 14M | 0dB, 12dB, 14dB | 9.7MHz - 14MHz Low Pass |
LTC6605-14 | 2 | 2 | Differential, Lowpass | Pin Configurable | 20M | 0dB, 6dB, 9.5dB | 12.4MHz - 20MHz Low Pass |
LTC6605-7 | 2 | 2 | Differential, Lowpass | Pin Configurable | 10M | 0dB, 12dB, 14dB | 6.5MHz - 10MHz Low Pass |
LT6604-10 | 4 | 2 | Differential, Lowpass | Chebyshev | 10M | Resistor Set | 10MHz Low Pass |
LT6604-15 | 4 | 2 | Differential, Lowpass | Chebyshev | 15M | Resistor Set | 15MHz Low Pass |
LT6604-2.5 | 4 | 2 | Differential, Lowpass | Chebyshev | 2.5M | Resistor Set | 2.5MHz Low Pass |
LT6604-5 | 4 | 2 | Differential, Lowpass | Chebyshev | 5M | Resistor Set | 5MHz Low Pass |
LT6600-15 | 4 | 1 | Differential, Lowpass | Chebyshev | 15M | Resistor Set | 15MHz Low Pass |
LT6600-5 | 4 | 1 | Differential, Lowpass | Chebyshev | 5M | Resistor Set | 5MHz Low Pass |
LT6600-2.5 | 4 | 1 | Differential, Lowpass | Chebyshev | 2.5M | Resistor Set | 2.5MHz Low Pass |
LT6600-10 | 4 | 1 | Differential, Lowpass | Chebyshev | 10M | Resistor Set | 10MHz Low Pass |
LT6600-20 | 4 | 1 | Differential, Lowpass | Chebyshev | 20M | Resistor Set | 20MHz Low Pass |
