PSoC 1 微控制器Cypress
发布时间：2024-01-23 17:17:17 浏览：750
PSoC 1 微控制器是全球首个可编程控制器内嵌式片上系统，在单独的芯片上搭载了可设置的数字调制外接设备功能、存储器和微控制器。PSoC 1 微控制器由Cypress独特的 8 位 M8C 核心提供保障，为控制系统用户提供模拟集成化、高效的 IO 路由及其可设置的数字调制外接设备。从而使得技术人员能够迅速设计系统并即时进行调整，同时减少 BOM 成本和开发周期。PSoC 1 微控制器由集成开发环境 PSoC Designer和简单易用的PSoC 1开发工具兼容。
Product | Frequency max [MHz] | Flash [kByte] | SRAM [kByte] | I/O Pins | Operating Voltage min [V] | Operating Voltage max [V] | Operating Temperature min [°C] | Operating Temperature max [°C] | Peak Reflow Temp [°C] |
CY8C21234-24SXIT |
|
|
|
|
|
|
|
|
|
CY8C21323-24LQXI |
|
|
|
|
|
|
|
|
|
CY8C21323-24LQXIT |
|
|
|
|
|
|
|
|
|
CY8C21534-24PVXIT |
|
|
|
|
|
|
|
|
|
CY8C23533-24LQXIT |
|
|
|
|
|
|
|
|
|
CY8C27243-24PVXIT |
|
|
|
|
|
|
|
|
|
CY8C27443-24PVXIT |
|
|
|
|
|
|
|
|
|
CY8C27443-24SXIT |
|
|
|
|
|
|
|
|
|
CY8C27543-24AXIT |
|
|
|
|
|
|
|
|
|
CY8C27643-24PVXIT |
|
|
|
|
|
|
|
|
|
CY8C29466-24SXIT |
|
|
|
|
|
|
|
|
|
CY8C29666-24PVXIT |
|
|
|
|
|
|
|
|
|
CY8C29866-24AXIT |
|
|
|
|
|
|
|
|
|
CY8C20324-12LQXI | 12 | 8 | 0.5 | 17 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C20324-12LQXIT | 12 | 8 | 0.5 | 17 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C20424-12LQXI | 12 | 8 | 0.5 | 25 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C20424-12LQXIT | 12 | 8 | 0.5 | 25 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C20524-12PVXI | 12 | 8 | 0.5 | 21 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C20524-12PVXIT | 12 | 8 | 0.5 | 21 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C20236A-24LKXI | 24 | 8 | 1 |
| 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20236A-24LKXIT | 24 | 8 | 1 | 13 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20246A-24LKXI | 24 | 16 | 2 | 13 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20246A-24LKXIT | 24 | 16 | 2 | 13 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20336A-24LQXI | 24 | 8 | 1 | 20 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20336A-24LQXIT | 24 | 8 | 1 | 20 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20346A-24LQXI | 24 | 16 | 2 | 20 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20346A-24LQXIT | 24 | 16 | 2 | 20 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20396A-24LQXI | 24 | 16 | 2 | 19 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20396A-24LQXIT | 24 | 16 | 2 | 19 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20436A-24LQXI | 24 | 8 | 1 | 28 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20436A-24LQXIT | 24 | 8 | 1 | 28 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20446A-24LQXI | 24 | 16 | 2 | 28 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20446A-24LQXIT | 24 | 16 | 2 | 28 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20466A-24LQXI | 24 | 32 | 2 | 28 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20466A-24LQXIT | 24 | 32 | 2 | 28 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20496A-24LQXI | 24 | 16 | 2 | 25 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20496A-24LQXIT | 24 | 16 | 2 |
| 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20536A-24PVXI | 24 | 8 | 1 | 34 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20536A-24PVXIT | 24 | 8 | 1 | 34 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20546A-24PVXI | 24 | 16 | 2 | 34 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20546A-24PVXIT | 24 | 16 | 2 | 34 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20636A-24LQXI | 24 | 8 | 1 | 36 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20636A-24LQXIT | 24 | 8 | 1 | 36 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20636A-24LTXI | 24 | 8 | 1 |
| 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20636A-24LTXIT | 24 | 8 | 1 |
| 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20646A-24LQXI | 24 | 16 | 2 | 36 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20646A-24LQXIT | 24 | 16 | 2 | 36 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20055-24SXI | 24 | 8 | 1 | 12 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20237-24LKXI | 24 | 8 | 1 | 14 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20237-24LKXIT | 24 | 8 | 1 | 14 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20247S-24LKXI | 24 | 16 | 2 | 13 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20247S-24LKXIT | 24 | 16 | 2 | 13 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20337-24LQXI | 24 | 8 | 1 | 20 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20337-24LQXIT | 24 | 8 | 1 | 20 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20437-24LQXI | 24 | 8 | 1 | 29 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20437-24LQXIT | 24 | 8 | 1 | 29 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20447S-24LQXI | 24 | 16 | 2 | 29 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20447S-24LQXIT | 24 | 16 | 2 | 29 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20637-24LQXI | 24 | 8 | 1 | 36 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20637-24LQXIT | 24 | 8 | 1 | 36 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20667S-24LQXI | 24 | 32 | 2 | 33 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C20667S-24LQXIT | 24 | 32 | 2 | 33 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C21123-24SXI | 24 | 4 | 0.25 | 6 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21123-24SXIT | 24 | 4 | 0.25 | 6 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21223-24SXI | 24 | 4 | 0.25 | 12 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21223-24SXIT | 24 | 4 | 0.25 | 12 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21323-24PVXI | 24 | 4 | 0.25 | 16 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21323-24PVXIT | 24 | 4 | 0.25 | 16 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21234-24SXI | 24 | 8 | 0.5 | 12 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21334-24PVXI | 24 | 8 | 0.5 | 16 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21334-24PVXIT | 24 | 8 | 0.5 | 16 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21334B-24PVXI | 24 | 8 | 0.5 | 12 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21334B-24PVXIT | 24 | 8 | 0.5 | 12 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21434-24LQXI | 24 | 8 | 0.5 | 28 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21434-24LQXIT | 24 | 8 | 0.5 | 28 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21434-24LTXI | 24 | 8 | 0.5 | 28 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21434-24LTXIT | 24 | 8 | 0.5 | 28 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21434B-24LTXI | 24 | 8 | 0.5 | 24 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21534-24PVXI | 24 | 8 | 0.5 | 24 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21534B-24PVXI | 24 | 8 | 0.5 | 20 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21534B-24PVXIT | 24 | 8 | 0.5 | 20 | 2.4 | 5.25 | -40 | 85 | 260 |
CY8C21345-24SXI | 24 | 8 | 0.51 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C21345-24SXIT | 24 | 8 | 0.51 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C22345-24SXI | 24 | 16 | 1 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C22345-24SXIT | 24 | 16 | 1 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C22545-24AXI | 24 | 16 | 1 |
| 3 | 5.25 | -40 | 85 | 260 |
CY8C22545-24AXIT | 24 | 16 | 1 | 38 | 3 | 5.25 | -40 | 85 | 260 |
CY8C23533-24LQXI | 24 | 8 | 0.25 | 26 | 3 | 5.25 | -40 | 85 | 260 |
CY8C24123A-24SXI | 24 | 4 | 0.25 | 6 | 3 | 5.25 | -40 | 85 | 260 |
CY8C24123A-24SXIT | 24 | 4 | 0.25 | 6 | 3 | 5.25 | -40 | 85 | 260 |
CY8C24223A-24PVXI | 24 | 4 | 0.25 | 16 | 3 | 5.25 | -40 | 85 | 260 |
CY8C24223A-24PVXIT | 24 | 4 | 0.25 | 16 | 3 | 5.25 | -40 | 85 | 260 |
CY8C24423A-24LTXI | 24 | 4 | 0.25 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C24423A-24LTXIT | 24 | 4 | 0.25 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C24423A-24PVXI | 24 | 4 | 0.25 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C24423A-24PVXIT | 24 | 4 | 0.25 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C24423A-24SXI | 24 | 4 | 0.25 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C24423A-24SXIT | 24 | 4 | 0.25 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C24633-24PVXI | 24 | 8 | 0.25 | 26 | 3 | 5.25 | -40 | 85 | 260 |
CY8C24633-24PVXIT | 24 | 8 | 0.25 | 26 | 3 | 5.25 | -40 | 85 | 260 |
CY8C24193-24LQXI | 24 | 8 | 1 | 28 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C24493-24LTXI | 24 | 32 | 2 | 36 | 1.71 | 5.5 | -40 | 85 | 260 |
CY8C27243-24PVXI | 24 | 16 | 0.25 | 16 | 3 | 5.25 | -40 | 85 | 260 |
CY8C27443-24PVXI | 24 | 16 | 0.25 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C27443-24SXI | 24 | 16 | 0.25 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C27543-24AXI | 24 | 16 | 0.25 | 40 | 3 | 5.25 | -40 | 85 | 260 |
CY8C27643-24LTXI | 24 | 16 | 0.25 | 44 | 3 | 5.25 | -40 | 85 | 260 |
CY8C27643-24LTXIT | 24 | 16 | 0.25 | 44 | 3 | 5.25 | -40 | 85 | 260 |
CY8C27643-24PVXI | 24 | 16 | 0.25 | 44 | 3 | 5.25 | -40 | 85 | 260 |
CY8C28243-24PVXI | 24 | 16 | 1 | 16 | 3 | 5.25 | -40 | 85 | 260 |
CY8C28243-24PVXIT | 24 | 16 | 1 | 16 | 3 | 5.25 | -40 | 85 | 260 |
CY8C28413-24PVXI | 24 | 16 | 1 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C28413-24PVXIT | 24 | 16 | 1 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C28433-24PVXI | 24 | 16 | 1 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C28433-24PVXIT | 24 | 16 | 1 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C28445-24PVXI | 24 | 16 | 1 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C28445-24PVXIT | 24 | 16 | 1 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C28452-24PVXI | 24 | 16 | 1 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C28452-24PVXIT | 24 | 16 | 1 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C28643-24LTXI | 24 | 16 | 1 | 44 | 3 | 5.25 | -40 | 85 | 260 |
CY8C28643-24LTXIT | 24 | 16 | 1 | 44 | 3 | 5.25 | -40 | 85 | 260 |
CY8C28645-24LTXI | 24 | 16 | 1 | 44 | 3 | 5.25 | -40 | 85 | 260 |
CY8C28645-24LTXIT | 24 | 16 | 1 | 44 | 3 | 5.25 | -40 | 85 | 260 |
CY8C29466-24PVXI | 24 | 32 | 2 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C29466-24PVXIT | 24 | 32 | 2 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C29466-24SXI | 24 | 32 | 2 | 24 | 3 | 5.25 | -40 | 85 | 260 |
CY8C29566-24AXI | 24 | 32 | 2 | 40 | 3 | 5.25 | -40 | 85 | 260 |
CY8C29566-24AXIT | 24 | 32 | 2 | 40 | 3 | 5.25 | -40 | 85 | 260 |
CY8C29666-24LTXI | 24 | 32 | 2 | 44 | 3 | 5.25 | -40 | 85 | 260 |
CY8C29666-24LTXIT | 24 | 32 | 2 | 44 | 3 | 5.25 | -40 | 85 | 260 |
CY8C29666-24PVXI | 24 | 32 | 2 | 44 | 3 | 5.25 | -40 | 85 | 260 |
CY8C29866-24AXI | 24 | 32 | 2 | 64 | 3 | 5.25 | -40 | 85 | 260 |
CY8C9520A-24PVXI | 24 | 3 | 0 | 20 | 3 | 5.25 | -40 | 85 | 260 |
CY8C9520A-24PVXIT | 24 | 3 | 0 | 20 | 3 | 5.25 | -40 | 85 | 260 |
CY8C9540A-24PVXI | 24 | 11 | 0 | 40 | 3 | 5.25 | -40 | 85 | 260 |
CY8C9540A-24PVXIT | 24 | 11 | 0 | 40 | 3 | 5.25 | -40 | 85 | 260 |
CY8C9560A-24AXI | 24 | 27 | 0 | 60 | 3 | 5.25 | -40 | 85 | 260 |
CY8C9560A-24AXIT | 24 | 27 | 0 | 60 | 3 | 5.25 | -40 | 85 | 260 |
